Powering A Sustainable Future

Since 2015, KLW has manufactured and delivered more than fifty EPA Certified and CARB Verified Tier 4 locomotives across the U.S.  Our customers include government entities, short line railroads and industrial customers, all with the same goals: emit less, consume less, and do more.  How does KLW meet those demands?

Innovation

Rail is already the most sustainable way to transport products over land for long distances. According to The Association of American Railroads, Railroads move one ton of freight nearly 500 miles per gallon of fuel and account for just 0.5% of total U.S. greenhouse gas emissions and just 1.7% of transportation-related greenhouse gas emissions.

KLW's goal is to further reduce emissions by aligning our goals with those of the California Air Resources Board and other leaders in our industry.  Our patented systems combined with engines from our partners, Cummins and MTU, utilize SCR after-treatment systems to provide scalable emissions reduction without additional degradation of the locomotive’s engine seen in EGR solutions.
3200 Nose (1)

Commitment to Quality

KLW partners with Cummins and MTU to provide the highest quality engines for low, medium, and high horsepower applications.  We also partner with CAF, TSA and TMV to provide world class AC Traction systems.

Continually Moving Forward

What does the sustainable locomotive look like?  The KLW 4400-ACT 4 is powered by a Cummins QSK95 engine which provides 950V DC to the electrical bus and incorporates KLW’s locomotive system integration.  Our locomotive design allows for the utilization of any power source to generate the required voltage as emissions reductions solutions evolve, low-carbon power technology matures, direction clarifies, infrastructures develop for new fuels, and new fuel costs align with operating ratio targets.

AltTech-1

More Efficient and Reliable Traction

Modernization:
  • IGBT Inverter Technology—Individual axle control
  • Two-Stage Low-Voltage AC Traction Motors
    • Smaller in size for equivalent HP
    • Faster Rotation
    • Lower power consumption Gear ratio
  • Double bearing pinion gear-stronger and serviceable
  • Traction motor combos offer single source interchangeability between various truck models
AltTech-4

Zero Emission Solutions

Fuel Cell, Battery, and Hybrid:
  • Current supplier application in passenger rail solutions
  • Duty cycle dependent, freight application under development
AltTech-2

This System Allows For Emissions Reduction

Tier 4:
  • Selective Catalytic reduction (SCR) vs. Exhaust Gas Recirculation (EGR)—Lower heat rejection, more compact cooling package and efficient fan operation; less degradation of and maintenance required on EGR systems.
  • Battery APU- Reduced parasitic loads on engine system, through captured energy, offsetting reduced horsepower from electrical draw of auxiliary systems.
  • Efficient Oil-Free Air Compressor from our partner, New York Air Brake.
  • 100% Renewable Diesel/HVO Capable
  • Pending Approval: 20% Bio-Diesel Capable
Battery APU Idle Reduction:
  • Offset fuel burn related to typical 50% idle time
  • Battery reduces start cycles of Prime Mover
  • Powers Auxiliary Air Compressor
  • Glycol-capable engine reduces cold-weather idle time
  • Improved AESS capability
  • Powers HVAC
AltTech-3

Dual-Fuel Internal Combustion Engine (ICE)

  • ICE Engine runs on either diesel alone or in combination with other sustainable fuels when available, including Hydrogen
  • Dual fuel addresses interoperability concerns as infrastructure develops and sustainable fuels become more readily available
  • Reduces emissions to assist in obtaining ESG commitments
  • Allows maintenance personnel to work with sustainable fuel options on familiar equipment
Battery APU Idle Reduction:
  • Offset fuel burn related to typical 50% idle time
  • Battery reduces start cycles of Prime Mover
  • Powers Auxiliary Air Compressor
  • Glycol-capable engine reduces cold-weather idle time
  • Improved AESS capability
  • Powers HVAC
Untitled design - 2023-08-16T133357.614



TERC Fuel Alternative

Untitled design - 2023-08-16T134501.483



FRA Funding Opportunities

Let Us Power Your Next Generation

Need additional information regarding funding or help financing locomotives for your fleet?
